- High sensitivity with door and window security detection.
- Integrated with temperature and humidity sensors for environmental monitoring.
- Ultra-wide distance transmission up to a line of sight of 10 km.
- IP67 waterproof and UV-resistant housing for applications in harsh environments.
- Built-in replaceable 4000 mAh battery and works for 5 years without replacement.
- Equipped with NFC for easy setup.
- It complies with LoRaWAN® standard network gateways and servers.
- Wireless transmission technology
- LoRaWAN®
- LoRaWAN® frequency band
- UE868
- LoRaWAN® Transmission Power Supply
- 16dBm
- LoRaWAN® Sensitivity
- -137 dBm at 300 bps
- LoRaWAN® Mode
- OTAA/ABP Class A
- Battery life
- Up to 10 years
- Device settings
- Mobile application via NFC
- Power input source
- Battery ER18505 Li-SOCl2 4000 mAh
- Cabinet Ingress Protection (IP)
- IP67
- Cabinet dimensions
- 105.6 × 85.3 × 27 mm
- Magnet dimensions
- 32 × 15 × 8 mm
- Physical installation
- Wall
- Operating temperature range
- -30°C to +70°C
- Operating relative humidity range
- 0% to 100% (non-condensing)
- detection conductor cable
- 1007UL#22AWG 260 mm
- Type of detection
- Normally closed
- Distance of the magnets
- 20-30 mm
- Hole spacing
- 22mm
- Temperature measurement range
- -30 ºC to +70 ºC
- Temperature measurement accuracy
- ±0.3 ºC
- Temperature sensor resolution
- 0.1ºC
- Humidity measurement range
- 0% to 100% HR
- Humidity measurement accuracy
- ±3%
